PleasevisitGIGABYTE'swebsitefordetailsonconguringtheaudiosoftware.

AudioJackCongurations:

Jack

Headphone/

2-channel

4-channel 5.1-channel 7.1-channel

Center/Subwoofer Speaker Out

a a

RearSpeakerOut

a a a

Side Speaker Out

Line In

Line Out/Front Speaker Out

a a a a

Mic In

USB 3.2 Gen 1 Type-A Port (Q-Flash Plus Port)

TheUSB3.2Gen1portsupportstheUSB3.2Gen1specicationandiscompatibletotheUSB2.0

specication.UsethisportforUSBdevices.BeforeusingQ-FlashPlus

(Note)

, make sure to insert the USB

ashdriveintothisportrst.

Center/Subwoofer Speaker Out (Orange)

Use this audio jack to connect center/subwoofer speakers.

Rear Speaker Out (Black)

Use this audio jack to connect rear speakers.

Side Speaker Out (Gray)

Use this audio jack to connect side speakers.

Line In (Blue)

The line in jack. Use this audio jack for line in devices such as an optical drive, walkman, etc.

Line Out/Front Speaker Out (Green)

The line out jack.

Mic In (Pink)

The Mic in jack.

• Whenremovingthecableconnectedtoabackpanelconnector,rstremovethecablefromyour

device and then remove it from the motherboard.

• Whenremovingthecable,pullitstraightoutfromtheconnector.Donotrockitsidetosideto

prevent an electrical short inside the cable connector.

(Note) Toenablethe Q-FlashPlusfunctionpleasevisitthe"UniqueFeatures"webpageofGIGABYTE's

website.

- 12 -
