Gigabyte GA-AX370M-Gaming 3 (rev. 1.x) [30/40] Apu sata port 0 1 asata3 0 1 connectors

& IOMMU

 EnablesordisablesAMDIOMMUsupport.(Default:Auto)

& Integrated Graphics

(Note)

Enables or disables the onboard graphics function.

Auto The BIOS will automatically enable or disable the onboard graphics depending on the

graphicscardbeinginstalled.(Default)

Disabled  Disablestheonboardgraphics.

& UMA Frame Buffer Size

(Note)

 Framebuffersizeisthetotalamountofsystemmemoryallocatedsolelyfortheonboardgraphicscontroller.

MS-DOS,forexample,willuseonlythismemoryfordisplay.Optionsare:Auto(default),32M,64M,128M,

256M, 512M, 1G, 2G.

& SATA Mode

 EnablesordisablesRAIDfortheSATAcontrollersintegratedintheChipsetorcongurestheSATAcontrollers

to AHCI mode.

RAID   EnablesRAIDfortheSATAcontroller.

AHCI   CongurestheSATAcontrollerstoAHCImode.AdvancedHostControllerInterface

(AHCI)isaninterfacespecicationthatallowsthestoragedrivertoenableadvanced

SerialATAfeaturessuchasNativeCommandQueuingandhotplug.(Default)

& APU SATA Port Enable (ASATA3 0, 1 Connectors)

 EnablesordisablestheSATAcontrollerintegratedintheCPU.(Default:Enabled)

& Chipset SATA Port Enable (SATA3 0, 1, 2, 3 Connectors)

 EnablesordisablestheSATAcontrollerintegratedintheChipset.(Default:Enabled)

& APU SATA Port 0/1 (ASATA3 0, 1 Connectors)

 DisplaystheinformationoftheconnectedSATAdevice(s).

& Chipset SATA Port 0/1/2/3 (SATA3 0, 1, 2, 3 Connectors)

 DisplaystheinformationoftheconnectedSATAdevice(s).

2-6 Chipset

(Note) This item is present only when you install a CPU that supports this feature.
