Gigabyte GA-H270-Gaming 3 (rev. 1.0) [12/44] 7 internal connectors

1-7 Internal Connectors

Readthefollowingguidelinesbeforeconnectingexternaldevices:

• First make sure your devices are compliant with the connectors you wish to connect.

• Before installing the devices, be sure to turn off the devices and your computer. Unplug the power

cord from the power outlet to prevent damage to the devices.

• After installing the device and before turning on the computer, make sure the device cable has

been securely attached to the connector on the motherboard.

1) ATX_12V_2X4

2) ATX

3) CPU_FAN

4) SYS_FAN1/2

5) CPU_OPT

6) SYS_FAN3_PUMP

7) CPU/DRAM/VGA/BOOT

8) LED_C

9) SATA EXPRESS

10) SATA3 0/1/2/3/4/5

11) M2A1_32G/M2A2_32G

12) BAT

13) F_PANEL

14) SPDIF_O

15) F_ AUDIO

16) F_USB30_1/F_USB30_2

17) F_USB1/F_USB2

18) COMA

19) TPM

20) CLR_CMOS

21) THB_C

6 13191415

18 8

- 12 -
