1-5 Installing an Expansion Card

Readthefollowingguidelinesbeforeyoubegintoinstallanexpansioncard:

• Make sure the motherboard supports the expansion card. Carefully read the manual that came

with your expansion card.

• Always turn off the computer and unplug the power cord from the power outlet before installing an

expansion card to prevent hardware damage.

B. Connecting the Graphics Cards

Step 1:

Observe the steps in "1-5 Installing an Expansion Card" and install CrossFire/SLI graphics cards on the PCI Express x16

slots.(Tosetupa2-Wayconguration,werecommendinstallingthegraphicscardsonthePCIEX16andPCIEX8slots.)

Step 2:

Insert the CrossFire

(Note 2)

/SLI bridge connectors in the CrossFire/SLI gold edge connectors on top of the cards.

Step 3:

Plug the display cable into the graphics card on the PCIEX16 slot.

1-6 Setting up AMD CrossFire

™

/NVIDIA

SLI

™

Conguration

A. System Requirements

- Windows 10/8.1/7 operating system

- A CrossFire/SLI-supported motherboard with two or more PCI Express x16 slots and correct driver

- CrossFire/SLI-ready graphics cards of identical brand and chip and correct driver

(Current GPUs that support 3-Way CrossFire technology include the

AMDRadeon

™

HD 6800, HD 6900, HD 7800,

HD7900,R9200,R7200,R9300,R7300,RX400seriesandabove.ForthelatestGPUsupportinformation,

please refer to the AMD website.)

(Note 1)

- CrossFire

(Note 2)

/SLI bridge connectors

- Apowersupplywithsufcientpowerisrecommended(Refertothemanualofyourgraphicscardsforthe

power requirement)

(Note 1) When using dual core graphics cards, only 2-way is supported.

(Note 2) The bridge connector(s) may be needed or not depending on your graphics cards.

Due to CPU limitations, read the following guidelines before installing the memory in Dual Channel mode.

1. Dual Channel mode cannot be enabled if only one memory module is installed.

2. When enabling Dual Channel mode with two or four memory modules, it is recommended that memory

of the same capacity, brand, speed, and chips be used.

The four memory sockets are divided into two channels and each channel has two memory sockets as following:

ChannelA:DDR4_2,DDR4_4

ChannelB:DDR4_1,DDR4_3

C.ConguringtheGraphicsCardDriver

C-1. To Enable CrossFire Function

After installing the graphics card driver in the operating system, go to the AMD RADEON SETTINGS screen.

Browse to Gaming\Global Settings and ensure AMD CrossFire is set to On.

Procedure and driver screen for enabling CrossFire/SLI technology may differ by graphics cards and

driverversion.Refertothemanualthatcamewithyourgraphicscardsformoreinformationabout

enabling CrossFire/SLI technology.

C-2. To Enable SLI Function

After installing the graphics card driver in the operating system, go to the NVIDIA Control Panel. Browse to the

CongureSLI,Surround,PhysX screen and ensure Maximize 3D performance is enabled.

DualChannelMemoryCongurationsTable:

DDR4_4 DDR4_2 DDR4_3 DDR4_1

2 Modules

- - DS/SS - - DS/SS

DS/SS - - DS/SS - -

4 Modules DS/SS DS/SS DS/SS DS/SS

(SS=Single-Sided, DS=Double-Sided, "- -"=No Memory)

- 10 -
