1-8 Internal Connectors
Read the following guidelines before connecting external devices:
• First make sure your devices are compliant with the connectors you wish to connect.
• Before installing the devices, be sure to turn off the devices and your computer. Unplug the power
cord from the power outlet to prevent damage to the devices.
• After installing the device and before turning on the computer, make sure the device cable has
been securely attached to the connector on the motherboard.
1) ATX_12V_2X2
2) ATX_12V_2X4
3) ATX
4) CPU_FAN
5) SYS_FAN1/2/3/4
6) SYS_FAN5_PUMP/SYS_FAN6_PUMP
7) CPU_OPT
8) EC_TEMP1/EC_TEMP2
9) D_LED1/D_LED2
10) LED_C1/LED_C2
11) NOISE_SENSOR
12) SATA3 0/1/2/3/4/5
13) M2P_SB/M2A_CPU/M2M_SB
14) F_PANEL
15) F_ AUDIO
16) F_U32C
17) F_U32
18) F_USB1/F_USB2
19) SPI_TPM
20) THB_C1/THB_C2
21) QFLASH_PLUS
22) CLR_CMOS
23) BAT
24) CPU/DRAM/VGA/BOOT
146 242111
17
16
23
3
8
12
20
6
18 515 19
5 1 2
10
9
8
22
13
13
13
5
47 109
- 15 -
