1-7 Back Panel Connectors

After installing the HDMI device, make sure to set the default sound playback device to HDMI.

(The item name may differ depending on your operating system.)

Tighten the antennas to the antenna connectors and then aim the antennas correctly for better

signal reception.

(Note) To enable the Q-Flash Plus function please visit the "Unique Features" webpage of GIGABYTE's

website.

USB 2.0/1.1 Port

TheUSBportsupportstheUSB2.0/1.1specication.UsethisportforUSBdevices.

SMA Antenna Connectors (2T2R)

Use this connector to connect an antenna.

HDMI Port

The HDMI port supports HDCP 2.3 and Dolby TrueHD and DTS HD Master

Audio formats. It also supports up to 192KHz/16bit 7.1-channel LPCM audio

output. You can use this port to connect your HDMI-supported monitor. The maximum supported reso-

lution is 4096x2160@30 Hz, but the actual resolutions supported are dependent on the monitor being

used.

USB 3.2 Gen 1 Port

TheUSB3.2Gen1portsupportstheUSB3.2Gen1specicationandiscompatibletotheUSB2.0

specication.UsethisportforUSBdevices.

USB 3.2 Gen 2 Type-A Port (Q-Flash Plus Port)

TheUSB3.2Gen2Type-AportsupportstheUSB3.2Gen2specicationandiscompatibletotheUSB3.2

Gen1andUSB2.0specication.UsethisportforUSBdevices.BeforeusingQ-FlashPlus

(Note)

, make sure

toinserttheUSBashdriveintothisportrst.

USB 3.2 Gen 2 Type-A Port (Red)

TheUSB3.2Gen2Type-AportsupportstheUSB3.2Gen2specicationandiscompatibletotheUSB3.2

Gen1andUSB2.0specication.UsethisportforUSBdevices.

USB Type-C

™

Port

ThereversibleUSBportsupportstheUSB3.2Gen2specicationandiscompatibletotheUSB3.2

Gen1andUSB2.0specication.UsethisportforUSBdevices.

RJ-45 LAN Port

The Gigabit Ethernet LAN port provides Internet connection at up to 2.5 Gbps data rate. The following

describes the states of the LAN port LEDs.

Activity LED

Connection/

Speed LED

LAN Port

Activity LED:Connection/Speed LED:

State Description

Green 2.5 Gbps data rate

Orange 1 Gbps data rate

Off 100 Mbps data rate

State Description

Blinking Data transmission or receiving is occurring

On No data transmission or receiving is occurring
