Box Contents
5
Z490 AORUS MASTER motherboard
5
Motherboard driver disc
5
User's Manual
5
Quick Installation Guide
5
Four SATA cables
5
One antenna
5
Two RGB LED strip extension cables
5
One noise detection cable
5
Two thermistor cables
5
One G Connector
Optional Items
2-port USB 2.0 bracket (Part No. 12CR1-1UB030-6*R)
eSATA bracket (Part No. 12CF1-3SATPW-4*R)
3.5" Front Panel with 2 USB 3.2 Gen 1 ports (Part No. 12CR1-FPX582-2*R)
The box contents above are for reference only and the actual items shall depend on the product package you
obtain. The box contents are subject to change without notice.
