Gigabyte Z390 AORUS XTREME WATERFORCE 5G (rev. 1.0) [6/140] Box contents

- 6 -

Box Contents

Z390 AORUS XTREME WATERFORCE motherboard

One water cooling kit

OneAORUSUSBashdrivewithdrivers

User's Manual

Quick Installation Guide

Six SATA cables

Two Wi-Fi antennas

One GC-SLI2PL bridge connector

Two addressable LED strip adapter cables

One RGB LED strip extension cable

Two thermistor cables

One G Connector

One AORUS RGB Fan Commander

One GC-OC Touch

M.2 screw(s)/M.2 standoff(s)

One Velcro Cable Tie

Optional Items



2-port USB 2.0 bracket (Part No. 12CR1-1UB030-6*R)



eSATA bracket (Part No. 12CF1-3SATPW-4*R)



3.5" Front Panel with 2 USB 3.1 Gen 1 ports (Part No. 12CR1-FPX582-2*R)



HDMI-to-DVI adapter (Part No. 12CT2-HDMI01-1*R)

* The box contents above are for reference only and the actual items shall depend on the product package you

obtain. The box contents are subject to change without notice.
