USB 2.0/1.1 Port

TheUSBportsupportstheUSB2.0/1.1specication.UsethisportforUSBdevices.

HDMI Port

The HDMI port supports HDCP 2.2 and Dolby TrueHD and DTS HD Master

Audio formats. It also supports up to 192KHz/16bit 8-channel LPCM audio out-

put. You can use this port to connect your HDMI-supported monitor. The maximum supported resolution

3.1Gen1andUSB2.0specication.UsethisportforUSBdevices.BeforeusingQ-FlashPlus,make

suretoinserttheUSBashdrive

(Note)

intothisportrst.

Center/Subwoofer Speaker Out

Use this audio jack to connect center/subwoofer speakers.

Rear Speaker Out

Use this audio jack to connect rear speakers.

Optical S/PDIF Out Connector

This connector provides digital audio out to an external audio system that supports digital optical audio.

Before using this feature, ensure that your audio system provides an optical digital audio in connector.

The Mic in jack.

AudioJackCongurations:

Jack

Headphone/

• If you want to install a Side Speaker, you need to retask either the Line in or Mic in jack to be

Side Speaker out through the audio driver.

• ToenableorconguretheaudioamplifyingfunctionfortheLineoutjack,pleaseaccessthe

HD Audio Manager application.

(The item name may differ depending on your operating system.)

(Note) TheUSBashdriveusedmustbeaUSB2.0ashdrive.
