![Gigabyte TRX40 AORUS XTREME (rev. 1.1) [10/112] 2 product specifications](/img/pdf.png)
Gigabyte TRX40 AORUS XTREME (rev. 1.1) [10/112] 2 product specifications
![Gigabyte TRX40 AORUS XTREME (rev. 1.1) [10/112] 2 product specifications](/views2/1666736/page10/bga.png)
- 10 -
Hardware Installation
1-2 ProductSpecications
CPU AMD Socket sTRX4:
- 3rd Generation AMD Ryzen
™
Threadripper
™
processors
(Go to GIGABYTE's website for the latest CPU support list.)
Chipset AMD TRX40
Memory 8 x DDR4 DIMM sockets supporting up to 256 GB (32 GB single DIMM capacity)
of system memory
Quad Channel memory architecture
Support for DDR4 3200/2933/2667/2400/2133 MHz memory modules
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
SupportforExtremeMemoryProle(XMP)memorymodules
(Go to GIGABYTE's website for the latest supported memory speeds and memory
modules.)
Audio Realtek
®
ALC4050H codec+Realtek
®
ALC1220-VB codec (rear panel audio)
Realtek
®
ALC4050H codec+ESS SABRE9218 DAC (front panel audio)
Support for DTS:X
®
Ultra
HighDenitionAudio
2/4/5.1/7.1-channel
Support for S/PDIF Out
LAN Intel
®
10GbE LAN chip (10 Gbit/5 Gbit/2.5 Gbit/1 Gbit/100 Mbit), supporting
2 RJ-45 ports
Wireless
Communication
Module
Intel
®
Wi-Fi 6 AX200
- Wi-Fi 802.11a/b/g/n/ac/ax, supporting 2.4/5 GHz Dual-Band
- BLUETOOTH 5.0
- Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate
* Actual data rate may vary depending on environment and equipment.
Expansion Slots 2 x PCI Express x16 slots, running at x16 (PCIEX16_1, PCIEX16_2)
2 x PCI Express x16 slots, running at x8 (PCIEX8_1, PCIEX8_2)
(The PCIEX16 and PCIEX8 slots conform to PCI Express 4.0 standard.)
Multi-Graphics
Technology
Support for AMD Quad-GPU CrossFire
™
and 4-Way/3-Way/2-Way AMD
CrossFire
™
technologies
Support for NVIDIA
®
Quad-GPU SLI
™
and 4-Way/3-Way/2-Way NVIDIA
®
SLI
™
technologies
Storage Interface CPU:
- 1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 SATA and PCIe
4.0 x4/x2 SSD support) (M2M)
- 1 x M.2 connector (Socket 3, M key, type 2280/22110 SATA and PCIe 4.0
x4/x2 SSD support) (M2Q)
Chipset:
- 1 x M.2 connector (Socket 3, M key, type 2280/22110 SATA and PCIe 4.0
x4/x2 SSD support) (M2P)
- 1 x M.2 connector (Socket 3, M key, type 2280 SATA and PCIe 4.0 x4/x2
SSD support) (M2C_SOCKET)
- 8 x SATA 6Gb/s connectors (SATA3 0~7)
* Refer to "1-9 Internal Connectors," for the installation notices for the M.2 and SATA
connectors.
Support for RAID 0, RAID 1, and RAID 10
