PRODUCT DATASHEETPRODUCT DATASHEET

MA610 600A

Clamp Meter + NCV

The MA610 is a fully loaded clamp meter

with multimeter functions including AC

Current, AC/DC Voltage, Resistance,

Frequency, and Capacitance. It also

has a built-in non-contact voltage (NCV)

detector to quickly check circuits and

wires for live voltages.

Features

• 1.2" (30mm) jaw size ﬁts conductors up to 500MCM

• Built-in Non-Contact Voltage (NCV) detector

• MultiMeter functions include Resistance,

Capacitance and Frequency

• Relative Mode for Capacitance

• Data Hold freezes reading on display

• Auto Power Off with disable and Low Battery indication

• Large backlit LCD display

• Complete with test leads, three AAA batteries,

and pouch

Ordering

MA610 N ......... 600A AC Clamp Meter

www.extech.com

Rev. 3/12/19

N Indicates products that are available with optional calibration traceable to NIST. Order with -NIST after part number.

UPC Code: 793950376119

Speciﬁcations Range Max Resolution Basic Accuracy

AC Current 600.0A 1mA ±2.0%

DC Voltage 600V 0.1mV ±0.8%

AC Voltage 600V 1mV ±1.2%

Non-Contact Voltage (NCV) 100 to 600V

Resistance 40MΩ 0.1Ω ±1.0%

Capacitance 100µF 0.01nF ±4%

Frequency 1MHz 0.01Hz ±0.1%

Diode/Continuity Yes

Dimensions/Weight 9x3x1.6" (228x77x41mm)/ 9.3oz (265g)
