HOLD

HOLD feature freezes the display for later view. LCD “ ” turns on. Press the HOLD

button momentarily to toggle the HOLD feature.

Relative mode; DC-Zero mode (Models 035 & 037 only)

◎

Relative mode allows the user to offset the meter consecutive measurements

with the main display displaying reading as the reference value. LCD “ ” turns on.

Press the (HOLD) button for one second or more to toggle Relative mode. When

in DCA functions (Models 035 & 037 only), however, DC-Zero mode instead will be

activated.

◎

DC-Zero mode (Models 035 & 037 only) is a feature to temporarily offset DCA

residue readings caused by residual magnetic field of the jaws in DCA functions. Press

the Zero (HOLD) button for one second or more to apply. The meter displays “dc_0”

on each activation before continuing measurements. Apply this mode repeatedly to get

a zero reading before making any DCA measurements for best measuring accuracy.

The meter will give 3 short beeps, however, to warn for null activation if the display

reading is beyond a reasonable residue of -5 to 5 DCA.

RECORD mode

Press REC button momentarily to activate MAX/MIN recording mode. LCD MAX & MIN

turn on. The meter beeps when new MAX (maximum) or MIN (minimum) reading is

updated. Press the button momentarily to read the MAX, MIN, and MAXMIN (active

measurement) readings in sequence. Press the button for 1 second or more to exit this

mode. Auto-Power-Off is disabled automatically in this mode.

5ms CREST mode

Press CREST button for one second or more to activate CREST mode (Instantaneous

PEAK-HOLD) to capture current or voltage peak values in duration as short as 5ms.

LCD & MAX turn on. The meter beeps when new MAX (maximum) or MIN

(minimum) reading is updated. Press the button momentarily to toggle the MAX and

MIN readings. Press the button for 1 second or more to exit this mode. Auto-Power-

Off is disabled automatically in this mode.

LCD Backlight and Auto-Backlight-Off (ABO)

Press the SELECT button for 1 second or more to toggle the LCD backlight. The ABO

mode turns the LCD backlight off automatically after idling for 10 minutes to extend

battery life. See Power-on Options section for disabling ABO.
