Clamp-on Regular ACA

RANGE

Accuracy

1) 2)

50Hz ~ 100Hz

600.0A

1.5% + 5d

100Hz ~ 400Hz

600.0A

2.0% + 5d

Induced error from adjacent current-carrying conductor:

<0.1A/A for Models 037, 035

<0.6A/A for Models 033, 031

For Models 033, 031, specified accuracy is for measurements made at the jaw

center. When the conductor is not positioned at the jaw center, add 2% to specified

accuracy for position errors

Clamp-on Regular DCA (Models 037 & 035 only)

RANGE

Accuracy

1) 2)

600.0A

2.0% + 5d

Induced error from adjacent current-carrying conductor: <0.1A/A

Specified with DC-Zero mode applied to offset the non-zero residual readings, if any

Hz Line Level Frequency (Models 037 & 033 only)

Function

Sensitivity

(Sine RMS)

Range

600V

50V

5.00Hz ~ 999.9Hz

Accuracy: 1%+5d

DC-bias, if any, not more than 50% of Sine RMS
