Electrical Specifications

Accuracy is ±(% reading digits + number of digits) or otherwise specified, at 23

C ±

C & less than 75% R.H.

True RMS Model 162s ACV & ACA clamp-on accuracies are specified from 5% to

100% of range or otherwise specified. Maximum Crest Factor are as specified below,

and with frequency spectrums, besides fundamentals, fall within the meter specified AC

bandwidth for non-sinusoidal waveforms.

DC Voltage

RANGE Accuracy

400.0 mV 0.3% + 3d

4.000V, 40.00V, 400.0V 0.5% + 3d

600V 1.0% + 4d

NMRR : >50dB @ 50/60Hz

CMRR : >120dB @ DC, 50/60Hz, Rs=1k

Input Impedance : 10M, 30pF nominal (1000M for 400.0mV range)

AC Voltage

RANGE Accuracy

50Hz ~ 500Hz

400.0mV

4.0% + 4d

50Hz ~ 60Hz

4.000V, 40.00V, 400.0V 1.0% + 4d

60Hz ~ 500Hz

4.000V, 40.00V, 400.0V 1.5% + 4d

50Hz ~ 500Hz

600V 2.0% + 4d

CMRR : >60dB @ DC to 60Hz, Rs=1k

Input Impedance: 10M, 30pF nominal

True RMS Model 162s Crest Factor: < 1.6 : 1 at full scale & < 3.2 : 1 at half scale

Selection by RANGE button manually, and is specified from AC 40mV (AC 60mV for

True RMS Model 162s) and up
