Ordering Information:

380926 ................2000A True RMS DC/AC Clamp/DMM

380926-NIST ......2000A True RMS DC/AC Clamp/DMM w/Calibration Traceable to NIST

TL805 ..................Spare Set of CAT. III-1000V Test Leads

CA899..................Large soft case with shoulder strap

Specifications Ranges Max. Resolution Basic Accuracy (%rdg+digits)

DC/AC Current (Clamp): 400A, 2000A 0.1A ±(2% + 5d)

DC/AC Current (DMM): 400μA, 4000μA, 40mA, 400mA 0.1μA ±(1.2% + 5d)

DC Voltage: 400mV, 4.0V, 40V, 400V, 1000V 0.1mV ±(1% + 2d)

AC Voltage: 4V, 40V, 400V, 1000V 1mV ±(1.2% + 5d)

Capacitance: 50nF, 500nF, 5.0μF, 50μF 10pF ±(3% + 5d)

Resistance: 400Ω, 4.0kΩ, 40kΩ, 400kΩ, 4MΩ, 40MΩ 0.1Ω ±(1% + 5d)

Frequency: 5Hz, 50Hz, 500Hz, 5kHz, 50kHz, 100kHz 0.01Hz ±(1% + 5d)

Duty Cycle: 1% to 99% 0.1% ±(1% + 5d)

Diode Check: yes

Continuity: yes

Dimensions/Weight: 10 x 2.9 x 1.5" (255x73x38mm) / 14oz. (380g)

380926 Features:

• Full function autoranging DMM includes

AC/DC Voltage and Current, Resistance, Capacitance,

Frequency, Duty Cycle, Diode and Continuity

• Current measurements to 2000A through

the clamp and 400mA via test leads

• Large 4000 count backlit display for high resolution

and easy viewing in dimly lit areas

• Basic DCV accuracy of 1% with 0.1mV resolution

and current resolution to 0.1μA

• Rugged 2" (50mm) jaws accomodate

one 2000MCM or two 500MCM cables

• Features include DCA push button zero,

Relative measurements and Data Hold

• Heavy duty ABS case with built-in stand

and thumb control function switch

• Complete with test leads and 9V battery

Full range multimeter functions

With high resolution to 0.1μA/0.1mV and CAT IV-600V Safety Rating

2000A AC/DC Clamp Meter

Specifications subject to change without notice.

www.extech.com

7/27/10 - R1

Large jaw size for high current measurements
