380942-EU-EN v2.2 07/13

Introduction

Congratulations on your purchase of the Extech Model 380942 DC/AC Clamp Meter. This meter is

shipped fully tested and calibrated and, with proper use, will provide years of reliable service.

Meter Description

1. Current sense jaw

2. Measurement Trigger

3. Function switch

4. Data HOLD key

5. MAX / MIN key

6. One-touch DCA ZERO key

7. LCD Display

8. Positive input terminal for Voltage

9. COM terminal

Safety Symbols and Information

Caution ! Refer to the explanation in this Manual

Caution ! Risk of electric shock

Earth (Ground)

This meter has been designed to be safe in use, but the operator must use caution in its operation.

The rules listed below should be carefully followed for safe operation.

1. NEVER apply voltage or current to the meter that exceeds the specified maximum:

2. USE EXTREME CAUTION when working with high voltages.

3. DO NOT measure voltage if the voltage on the "COM" input jack exceeds 600V above earth

ground.

4. ALWAYS turn off the power and disconnect the test leads before opening the back to replace

the fuse or batteries.

5. NEVER operate the meter unless the back cover and the battery/fuse door are in place and

fastened securely.
