Specifications subject to change without notice.

www.extech.com

7/19/11 - R1

Integrated Non-Contact Voltage Detector

o quickly check for the presence of live wires before testing plus

True RMS and 400A and 1500A current ranges

1500A True RMS AC/DC Clamp Meter + NCV

Ordering Information:

MA1500............1500A True RMS AC/DC Clamp Meter + NCV

MA1500-NIST ..1500A True RMS AC/DC Clamp Meter + NCV w/ Calibration Traceable to NIST.

Features:

• True RMS for accurate readings of non-sinusoidal waveforms

• Built-in non-contact Voltage detector with LED alert

• 2.0" (52mm) jaw size for conductors up to 500MCM

• Dual 40,000/4000 count, backlit LCD display

• Includes Multimeter functions

• Inrush function captures transients during motor startups

• Relative Mode for Capacitance Zero and Offset Adjustment

• Data Hold, Peak Hold, MIN/MAX, and Auto Power Off

• Complete with test leads, general purpose Type K bead wire

temperature probe, 9V battery and carrying case

Built-in non-contact Voltage detector with LED alert

2.0" (52mm) jaw size for conductors up to 500MCM

Test leads included for Multimeter functions

Specifications Range Max. Resolution Basic Accuracy

(% readings+digits)

Display counts 40,000/4,000

AC Current (True RMS) 400.00A, 1500.0A 0.01A ±(2.8% + 30d)

DC Current 400.00A, 1500.0A 0.01A ±(2.5% + 30d)

AC Voltage (True RMS) 400.00mV, 4.000V, 40.00V, 750.0V 0.01mV ±(1.0% + 30d)

DC Voltage 400.00mV, 4.0000V, 40.000V, 1000.0V 0.01mV ±(0.1% + 4d)

Resistance 400.00Ω, 4.0000kΩ, 40.000kΩ,

400.00kΩ, 4.0000ΜΩ, 40.000MΩ 0.01Ω ±(0.5% + 9d)

Frequency 40Hz to 40MHz 0.001Hz ±(0.3% + 2d)

Capacitance 400.00nF, 4000nF, 40.00µF, 400.0µF,

4.000mF, 20.00mF, 40.00mF 0.01nF ±(3.5% + 10d)

Temperature -148 to 1832°F (-100 to 1000°C) 0.1° ±(1% + 4.5°F/2.5°C)

Duty Cycle 10.0 to 95.0% 0.1% ±(1.0% + 2d)

Diode Yes

Continuity Yes

Dimensions 11.57x4.13x1.85" (294x105x47mm)

Weight 18.9oz (536g)
