3 Fluke Corporation Fluke 370 FC Series True-rms Wireless AC/DC Clamp Meters
Comparison chart
Fluke 376 FC Fluke 375 FC Fluke 374 FC
CAT rating CAT III 1000 V, CAT IV 600 V CAT III 1000 V, CAT IV 600 V CAT III 1000 V, CAT IV 600 V
A ac range 999.9 A with clamp jaws
2500 A with iFlex
®
flexible
current clamp
600 A with clamp jaws
2500 A with optional iFlex
®
flexible current clamp
600 A with clamp jaws
2500 A with optional iFlex
®
flexible current clamp
A dc range 999.9 A 600 A 600A
Best resolution 0.1 A 0.1 A 0.1 A
V ac range 1000 V 1000 V 1000 V
V dc range 1000 V 1000 V 1000 V
mV dc range 500 mV 500 mV
Ohms range 60.00 kΩ 60.00 kΩ 6,000 Ω
Frequency 5-500.0 Hz 5-500.0 Hz
Capacitance 1 μF-1,000 μF 1 μF-1,000 μF 1 μ-1,000 μF
Auto shutoff
• • •
True RMS
• • •
Display hold
• • •
Inrush measurements
• • •
Backlight
• • •
DC zero
• • •
Min/max
• • •
VFD low pass filter
• •
Logging
• •
iFlex
®
flexible current clamp Included Optional Optional
Fluke Connect
®
compatible
• • •
Specifications
General specifications
Maximum voltage between any terminal and earth ground 1000 V
Battery type 2 AA alkaline batteries, NEDA 15A, IEC LR6
Temperature Operating: -10 °C to +50 °C (14 °F to + 122 °F)
Storage: -40 °C to +60 °C (-40 °F to + 140 °F)
Operating humidity Non condensing (< 10 °C (50 °F)), ≤90 % RH (at 10 °C to 30 °C (50 °F to 86 °F)),
≤75 % RH (at 30 °C to 40 °C (86 °F to 104 °F)), ≤45 % RH (at 40 °C to 50 °C
(104 °F to 122 °F))
Altitude Operating: 3,000 m (9,842 ft)
Storage: 12,000 m (39,370 ft)
Dimensions 24.9 cm (9.8 in) x 8.5 cm (3.3 in) x 4.5 cm (1.7 in)
Weight 395 g (13.9 oz)
Jaw opening 34 mm (1.3 in)
Flexible current probe diameter 7.5 mm (.29 in)
Flexible current probe cable length
(head to electronics connector)
1.8 m (70.8 in)
Safety IEC 61010-1, Pollution Degree 2
IEC 61010-2-032: CAT III 1000 V / CAT IV 600 V
IEC 61010-2-033: CAT III 1000 V / CAT IV 600 V
IP rating IEC 60529: IP30, non-operating
Radio frequency certification FCC ID:T68-FBLE IC:6627A-FBLE
