- 11 -
Hardware Installation
Expansion Slots Integrated in the Chipset (PCIEX4):
- 1 x PCI Express x16 slot, supporting PCIe 4.0
(Note 1)
/3.0 and running at x4
Multi-Graphics
Technology
(Note 2)
Support for NVIDIA
®
Quad-GPU SLI
™
and 2-Way NVIDIA
®
SLI
™
technologies
Support for AMD Quad-GPU CrossFire
™
and 2-Way AMD CrossFire
™
technologies
Storage Interface Integrated in the CPU (M2A_SOCKET):
3rd Generation AMD Ryzen
™
processors
:
- 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and
PCIe 4.0 x4/x2 SSD support)
2nd Generation AMD Ryzen
™
processors/2nd Generation AMD Ryzen
™
with Radeon
™
Vega Graphics processors/AMD Ryzen
™
with Radeon
™
Vega Graphics processors
:
- 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and
PCIe 3.0 x4/x2 SSD support)
Integrated in the Chipset (M2B_SOCKET/M2C_SOCKET):
- 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and
PCIe 4.0
(Note 1)
/3.0 x4/x2 SSD support) (M2B_SOCKET)
- 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and
PCIe 4.0
(Note 1)
/3.0 x4/x2 SSD support) (M2C_SOCKET)
- 6 x SATA 6Gb/s connectors
- Support for RAID 0, RAID 1, and RAID 10
* Refer to "1-9 Internal Connectors," for the installation notices for the M.2 and SATA
connectors.
USB Integrated in the CPU:
- 2 x USB 3.2 Gen 2
(Note 1)
/Gen 1 Type-A ports (red) on the back panel
- 2 x USB 3.2 Gen 1 ports on the back panel
Integrated in the Chipset:
- 1 x USB Type-C
™
port with USB 3.2 Gen 2 support, available through the
internal USB header
- 1 x USB Type-C
™
port on the back panel, with USB 3.2 Gen 2 support
- 3 x USB 3.2 Gen 2 Type-A ports (red) on the back panel
- 2 x USB 3.2 Gen 1 ports available through the internal USB header
Chipset+USB 3.2 Gen 1 Hub:
- 2 x USB 3.2 Gen 1 ports available through the internal USB header
- 2 x USB 2.0/1.1 ports available through the internal USB header
Chipset+USB 2.0 Hub:
- 4 x USB 2.0/1.1 ports on the back panel
(Note 1) For
3rd Generation AMD Ryzen
™
processors
only.
(Note 2) For
3rd Generation AMD Ryzen
™
processors
/
2nd Generation AMD Ryzen
™
processors
only.
