Hardware Installation

1-7 Back Panel Connectors

Q-Flash Plus Button

(Note 1)

This button allows you to update the BIOS when the power connector is connected but the system is not

powered on.

Clear CMOS Button

UsethisbuttontocleartheCMOSvalues(e.g.BIOSconguration)andresettheCMOSvaluestofactory

defaults when needed.

• Always turn off your computer and unplug the power cord from the power outlet before using

the clear CMOS button.

• Do not use the clear CMOS button when the system is on, or the system may shutdown and

data loss or damage may occur.

• After system restart, go to BIOS Setup to load factory defaults (select Load Optimized Defaults) or

manuallyconguretheBIOSsettings(refertoChapter2,"BIOSSetup,"forBIOScongurations).

USB 2.0/1.1 Port

TheUSBportsupportstheUSB2.0/1.1specication.UsethisportforUSBdevices.

SMA Antenna Connectors (2T2R)

Use this connector to connect an antenna.

Tighten the antenna cables to the antenna connectors and then move the antenna to a place

where the signal is good.

USB 3.2 Gen 1 Port

TheUSB3.2Gen1portsupportstheUSB3.2Gen1specicationandiscompatibletotheUSB2.0

specication.UsethisportforUSBdevices.

USB 3.2 Gen 1 Port (White)

TheUSB3.2Gen1portsupportstheUSB3.2Gen1specicationandiscompatibletotheUSB2.0

specication.UsethisportforUSBdevices.BeforeusingQ-FlashPlus

(Note 1)

, make sure to insert the

USBashdriveintothisportrst.

USB 3.2 Gen 2

(Note 2)

/Gen 1 Type-A Port (Red)

The USB 3.2 Gen 2

(Note 2)

/Gen1Type-AportsupportstheUSB3.2Gen2specicationandiscompatible

totheUSB3.2Gen1andUSB2.0specication.UsethisportforUSBdevices.

RJ-45 LAN Port (LAN2)

The Gigabit Ethernet LAN port provides Internet connection at up to 1 Gbps data rate. The following

describes the states of the LAN port LEDs.

(Note 1) To enable Q-Flash Plus function, refer to Chapter 5, "Unique Features," for more information.

(Note 2) For

3rd Generation AMD Ryzen

™

processors

only.

Activity LED

Connection/

Speed LED

LAN Port

Activity LED:Connection/Speed LED:

State Description

Orange 1 Gbps data rate

Green 100 Mbps data rate

Off 10 Mbps data rate

State Description

Blinking Data transmission or receiving is occurring

On No data transmission or receiving is occurring
