Gigabyte X570 AORUS PRO WIFI (rev. 1.1/1.2) [14/48] Center subwoofer speaker out

• If you want to install a Side Speaker, you need to retask either the Line in or Mic in jack to be

Side Speaker out through the audio driver.

• ToenableorconguretheaudioamplifyingfunctionfortheLineoutjack,pleaseaccessthe

HD Audio Manager application.

PleasevisitGIGABYTE'swebsitefordetailsonconguringtheaudiosoftware.

AudioJackCongurations:

Jack

Headphone/

2-channel

4-channel 5.1-channel 7.1-channel

Line Out/Front Speaker Out

Mic In/Side Speaker Out

USB 3.2 Gen 2 Type-A Port (Red)

The USB 3.2 Gen 2 Type-A port supports the USB 3.2 Gen 2

3.2Gen1andUSB2.0specication.UsethisportforUSBdevices.

USB Type-C

Port

Rear Speaker Out

Use this audio jack to connect rear speakers.

Optical S/PDIF Out Connector

This connector provides digital audio out to an external audio system that supports digital optical audio.

Before using this feature, ensure that your audio system provides an optical digital audio in connector.

Line In/Side Speaker Out

The line in jack. Use this audio jack for line in devices such as an optical drive, walkman, etc.

Line Out/Front Speaker Out

The line out jack. This jack supports audio amplifying function. For better sound quality, it is recommended

that you connect your headphone/speaker to this jack (actual effects may vary by the device being used).

(Note 2) To enable the Q-Flash Plus function please visit the "Unique Features" webpage of GIGABYTE's

(Note 3) For 3rd Generation AMD Ryzen

™

processors only.
