Please visit GIGABYTE's website for support lists of CPU, memory
modules, SSDs, and M.2 devices.
Please visit the Support\Utility List page on GIGABYTE's website to download the latest
version of apps.
B550 AORUS PROB550 AORUS PRO AC
Bundled
Software
Norton
®
Internet Security (OEM version)
XSplit Gamecaster + Broadcaster (12 months license)
Realtek
®
8125 Gaming LAN Bandwidth Control Utility
Operating
System
Support for Windows 10 64-bit
Form Factor ATX Form Factor; 30.5cm x 24.4cm
* GIGABYTE reserves the right to make any changes to the product specications and product-related information without
prior notice.
- 10 -
