USB Chipset:
- 2 x USB 2.0/1.1 ports available through the internal USB header
- 8 x USB 3.1 Gen 1 ports (6 ports on the back panel, 2 ports available through
the internal USB header)
- 1 x USB Type-C
™
port on the back panel, with USB 3.1 Gen 1 support
Internal
Connectors
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x CPU fan header
2 x system fan headers
1 x digital LED strip header
1 x digital LED strip power select jumper
1 x RGB (RGBW) LED strip header
4 x SATA 6Gb/s connectors
2 x M.2 Socket 3 connectors(one on the back of the motherboard)
1 x front panel header
1 x front panel audio header
1 x USB 3.1 Gen 1 header
1 x USB 2.0/1.1 header
1 x S/PDIF Out header
1 x speaker header
1 x Clear CMOS jumper
1 x chassis intrusion header
Back Panel
Connectors
2 x HDMI ports
1 x DisplayPort
2 x SMA antenna connectors (2T2R)
6 x USB 3.1 Gen 1 ports
1 x USB Type-C
™
port, with USB 3.1 Gen 1 support
2 x RJ-45 ports
3 x audio jacks
I/O Controller iTE
®
I/O Controller Chip
Hardware
Monitor
Voltage detection
Temperature detection
Fan speed detection
Overheating warning
Fan fail warning
Fan speed control
* Whether the fan speed control function is supported will depend on the cooler you
install.
BIOS 2 x 128 Mbit ash
Use of licensed AMI UEFI BIOS
Support for DualBIOS
™
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
- 8 -
