Gigabyte B365M POWER (rev. 1.0) [4/44] B365m power motherboard layout
![Gigabyte B365M POWER (rev. 1.0) [4/44] B365m power motherboard layout](/views2/1667984/page4/bg4.png)
- 4 -
B365M POWER Motherboard Layout
* The box contents above are for reference only and the actual items shall depend on the product package you obtain.
The box contents are subject to change without notice.
Box Contents
5 B365M POWER Motherboard
5 SATA cable(s) 5 I/O Shield
KB_MS
CPU_FAN
SYS_FAN
LGA1151
ATX
B365M POWER
F_AUDIO
AUDIO
BAT
ATX_12V_2X4
Intel
®
B365
R_USB30_1
CODEC
CLR_CMOS
M_BIOS
VGA
USB_LAN
PCIEX16
PCIEX1
iTE
®
Super I/O
Realtek
®
GbE LAN
F_USB1
F_USB2
F_PANEL
SATA3
5 4
3 2
DVI
COM
F_USB30
R_USB30_2
TPM
DDR4_1
DDR4_2
M2M
6080 42
