Gigabyte B365M D2V (rev. 1.0) [4/46] B360m d2v motherboard layout

- 4 -

B365M D2V Motherboard Layout

* The box contents above are for reference only and the actual items shall depend on the product package you obtain.

The box contents are subject to change without notice.

Box Contents

5 B365M D2V Motherboard 5 Two SATA cables

5 Motherboard driver disk 5 I/O Shield

5 User's Manual

KB_MS

CPU_FAN

SYS_FAN

LGA1151

ATX

B365M D2V

F_AUDIO

AUDIO

BAT

ATX_12V_2X4

Intel

B365

R_USB30_1

CODEC

CLR_CMOS

BIOS

VGA

USB_LAN

PCIEX16

PCIEX1_1

PCIEX1_2

iTE

Super I/O

Realtek

GbE LAN

F_USB1F_USB2 F_PANEL

SATA3

5 4

3 2

1 0

DVI

COM

F_USB30

R_USB30_2

TPM

DDR4_1

DDR4_2

M2M

6080 42
