- 4 -
GA-H310TN-R2 Motherboard Layout
* The box contents above are for reference only and the actual items shall depend on the product package you
obtain. The box contents are subject to change without notice.
Box Contents
5 GA-H310TN-R2 motherboard 5 One SATA power cable
5 Motherboard driver disc 5 Two SATA cables
5 User's Manual 5 Two I/O Shields (high/low)
5 One COM port cable
DC_PWR
ATX_12V
80
60
30
F_USB30
CPU_FAN
LGA1151
BAT
SATA_PWR
Intel
®
H310
M_BIOS
SYS_FAN
GA-H310TN-R2
MIC_IN
FPD_PWR
COMA
CNVI
SATA3
SATA3
0
1
FPD
F_PANEL
LVDS
(Note)
M2A
LINE_OUT
F_AUDIO
CODEC
SPKR
BAT_CON
Realtek
®
GbE LAN
iTE
®
Super I/O
(Note)
F_USB
TPM IC
SPEAKER
CLR_CMOS
CI
LCD_VCC
COMB
DP_HDMI
LAN
R_USB30
R_USB
DDR4_1
DDR4_2
BL_SW
MON_SW
(Note) The connector/chip is on the back of the motherboard.
