4
Before you start
• All repairs and technical service should
be made by qualified specialist from service
centers.
All images provided herein are schematic
drawings of real objects and may differ
from their real images.
Connection
Before you start connection of external
devices, ensure that power of the unit is
switched off.
Following outputs are available in this unit.
Audio/video output
Audio-video output is intended for
connecting an external display to this unit. For
connection use the included audio-video cable.
Coaxial audio output
The coaxial output is intended for connection
of an external multi-channel amplifier with
digital input. For connection use a cable with
3.5-mm jack.
Headphone jack
Connect your headphones to this unit by
using the headphone output. When headphone
is connected, the built-in speakers are mute.
Power connection
• For power supply from the electric mains
outlet 220 V, connect the included power
adaptor to the DC adaptor jack of this unit. Do
not use other DC adaptors.
• For power supply from the vehicle power
circuit, connect the car adaptor to the DC
adaptor jack of this unit. Do not use other car
adaptors.
• Power supply can be performed from the
built-in Li-Ion battery of this unit. The battery
power is enough for about 1-1.5 hours of
operation. The battery charge is performed
automatically when the unit is connected to
external power supply.
TV antenna jack
Connect the included TV antenna to the TV
antenna jack for reception of TV signal.
