Box Contents
5 H310M DS2V 2.0 motherboard
5 Motherboard driver disk 5 Two SATA cables
5 User's Manual 5 I/O Shield
- 4 -
H310M DS2V 2.0 Motherboard Layout
* The box contents above are for reference only and the actual items shall depend on the product package you obtain.
The box contents are subject to change without notice.
KB_MS_USB
VGADVI
R_USB30
USB_LAN
LGA1151
ATX
AUDIO
DDR4_2
DDR4_1
ATX_12V_2X4
Intel
®
H310
CLR_CMOS
M_BIOS
PCIEX1_1
PCIEX16
PCIEX1_2
F_USB30
CODEC
H310M DS2V 2.0
F_PANEL
F_USB
TPM
F_AUDIO
SYS_FAN
CPU_FAN
iTE
®
Super I/O
SATA3
BAT
Realtek
®
GbE LAN
1 3
0 2
