1-7 Internal Connectors
Read the following guidelines before connecting external devices:
• First make sure your devices are compliant with the connectors you wish to connect.
• Before installing the devices, be sure to turn off the devices and your computer. Unplug the power
cord from the power outlet to prevent damage to the devices.
• After installing the device and before turning on the computer, make sure the device cable has
been securely attached to the connector on the motherboard.
1) ATX_12V_2X4
2) ATX
3) CPU_FAN
4) SYS_FAN
5) SATA3 0/1/2/3
6) M2A
7) F_PANEL
8) F_ AUDIO
9) F_USB30
10) F_USB
11) TPM
12) CLR_CMOS
13) BAT
14) SPKR
4 1 3 2
10
6
13
7
8 11
9
5
14
12
- 12 -
