2 Fluke Corporation Fluke T6 Electrical Testers with FieldSense technology
Specifications
Measurement Specifications
General Specifications
T6-600 T6-1000
Function Requires test leads Range Range Resolution Accuracy
[1]
FieldSense ac voltage No 600 V 1000 V 1 V
±(3 % + 3 counts)
[2] [3]
45 Hz - 66 Hz
FieldSense ac current No 200.0 A 200.0 A 0.1 A
±(3 % + 3 counts)
45 Hz - 66 Hz
FieldSense frequency
(Hz)
No 45 Hz – 66 Hz 1 Hz
±(1 % + 2 counts)
[3]
Volts ac Yes 600 V 1000 V 1 V
±(1.5 % + 2 counts)
45 Hz - 66 Hz
Volts dc Yes 600 V 1000 V 1 V ±(1 % + 2 counts)
Resistance Yes 2000 Ω 2000 Ω 1 Ω ±(1 % + 2 counts)
Yes 20.00 kΩ 0.01 kΩ ±(1 % + 2 counts)
Yes 100.0 kΩ 0.1 kΩ ±(1 % + 2 counts)
Safety
(measurement category)
600 V CAT III
1000 V CAT III
600 V CAT IV
Accuracy
(1)
: ± ( [ % of reading] + [number of least significant digits] ). Accuracy is specified for 1 year after calibration, at 18 °C to 28 °C (64 °F to 82 °F)
with relative humidity to 90 %. AC conversions are ac-coupled, RMS responding.
Accuracy
(2)
: Add 3 % without an external ground connection. External ground connection required for user wearing insulated gloves, standing on an
insulated ladder and otherwise insulated from earth ground.
Accuracy
(3)
: FieldSense specified from 16V to 100% of range.
Calibration 1-year calibration cycle
Dimensions 61.1 mm x 259.3 mm x 43.8 mm
Weight 0.35 kg (0.78 lb)
Fork opening 17.8 m m
Temperature
Operating:
Storage:
-10 °C to +50 °C (14 °F to 122 °F)
-30 °C to +60 °C (-22 °F to +140 °F)
Altitude
Operating:
Storage:
2,000 m (6,562 feet)
10,000 m (32,808 feet)
Relative Humidity 0 % to 90 %, 5 °C to 30 °C (41 °F to 86 °F)
0 % to 75 %, 30°C to 40 °C (86 °F to 104 °F)
0 % to 45 %, 40°C to 50 °C (104 °F to 122 °F)
Battery Type and Life 2 x AA (IEC LR6); 360 hours continuous, typical; 200 hours using
FieldSense
Temperature coefficient 0.1 x (specified accuracy) / °C for <18°C or >28 °C
(< 64.4 °F or > 82.4 °F)
Safety IEC/EN 61010-1, IEC/EN 61010-2-033: Pollution Degree 2
Electromagnetic Environment IEC/EN 61326-1: Portable
Ordering information
Fluke T6-600 Electrical Tester
Fluke T6-1000 Electrical Tester
Included with product
Attached test leads with removable 4 mm probe caps,
user documentation
Optional accessories
H-T6 Belt Holster
TPAK Magnetic Hanger
PRV240FS Proving Unit
TP1 Probe Set, Flat-Blade (US/UK flat tip)
TP38 Probe set, round (EU)
AC285 SureGrip Alligator Clips
AC220 SureGrip Alligator Clips
Service Information Sheet, PN 686953
Fluke Corporation
PO Box 9090, Everett, WA 98206 U.S.A.
Fluke Europe B.V.
PO Box 1186, 5602 BD
Eindhoven, The Netherlands
Fluke. Keeping your world
up and running.
®
For more information call:
In the U.S.A. (800) 443-5853 or
Fax (425) 446-5116
In Europe/M-East/Africa +31 (0)40 267 5100
or Fax +31 (0)40 267 5222
In Canada (800)-36-FLUKE or
Fax (905) 890-6866
From other countries +1 (425) 446-5500 or
Fax +1 (425) 446-5116
Web access: http://www.fluke.com
©2017 Fluke Corporation.
Specifications subject to change without notice.
8/2017 6009251b-en
Modification of this document is not
permitted without written permission
from Fluke Corporation.
* Two-year additional warranty offer may be discontinued without notice
