Gigabyte H310M S2H (rev. 1.0) [4/42] H310m s2h motherboard layout

- 4 -

H310M S2H Motherboard Layout

* The box contents above are for reference only and the actual items shall depend on the product package you

obtain. The box contents are subject to change without notice.

Box Contents

5 H310M S2H motherboard

5 Motherboard driver disk 5 Two SATA cables

5 User's Manual 5 I/O Shield

KB_MS

CPU_FAN

SYS_FAN

ATX

H310M S2H

AUDIO

DDR4_1

DDR4_2

BAT

ATX_12V_2X4

Intel

H310

F_USB30

R_USB

CODEC

CLR_CMOS

M_BIOS

VGA

DVI

HDMI

PCIEX16

PCIEX1_1

PCIEX1_2

iTE

Super

I/O

Realtek

GbE LAN

F_PANELF_USBF_AUDIO TPM

1 3

0 2

M2A

426080

LGA1151

USB_LAN

R_USB30

SATA3
