EXTECH EX380363 [5/10] Ac dc voltage measurement

Model 380363-EU-EN-V-3.1-1/12

AC/DC Voltage Measurement

1. Set the Rotary switch to the

V position.

2. Connect the red test lead to the VΩ terminal and the black test lead to the COM terminal.

3. Connect the test leads to the circuit under test.

4. Read the voltage value on the LCD. The meter shows DC voltage in the upper right and AC

voltage on the main display.

Resistance Measurement and Audible Continuity Test

WARNING

Do not run this test unless ACV = 0. Do not use this mode to check diodes.

1. Set the Rotary switch to the Ω position.

2. Connect the red test lead to the VΩ terminal and the black lead to the COM terminal.

3. Connect the tips of the test leads to the circuit under test.

4. Read the resistance value on the display. When the resistance of a circuit is less than approx.

100Ω ± 80Ω, the audible tone will sound.

LOΩ Low Resistance Measurement

1. Set the Rotary switch to the LoΩ position.

2. Connect the red test lead to the VΩ terminal and the black lead to the COM terminal.

3. Touch the test leads together and press the

key to zero the display.

4. Connect the probes to the ciruit under test. If there is a voltage present, it will be displayed. A

repetitive beep and the flashing high voltage symbol

will be displayed if the voltage is over

30V. Remove the voltage before proceeding to the next step.

5. Press and hold the TEST key until a stable reading is displayed.

6. Release the TEST key. The upper right hand display will hold the reading until a new test is

started or a different function is selected.

7. Swap the red and black probes to reverse the polarity of the test current. The reading should

remain the same. This test is useful to detect corroded connections which can cause different

readings in both polarities.
