Storage Interface Chipset:
- 2 x M.2 connectors (Socket 3, M key, type 2242/2260/2280 SATA & PCIe
x4/x2/x1 SSD support)
- 3 x SATA Express connectors
- 6 x SATA 6Gb/s connectors
- SupportforRAID0,RAID1,RAID5,andRAID10
* Refer to"1-9InternalConnectors," forthe supportedcongurations withthe M.2,
SATA Express, and SATA connectors.
USB Chipset:
- 7 x USB 3.0/2.0 ports (3 ports on the back panel, 4 ports available through
the internal USB headers)
- 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through
the internal USB headers)
Chipset+Intel
®
USB 3.1 Controller:
- 1 x USB Type-C
™
port on the back panel, with USB 3.1 support
- 1 x USB 3.1 Type-A port (red) on the back panel
Internal
Connectors
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
2 x M.2 Socket 3 connectors
3 x SATA Express connectors
6 x SATA 6Gb/s connectors
1 x CPU fan header
1 x water cooling fan header (CPU_OPT)
3 x system fan headers
1 x front panel header
1 x front panel audio header
1 x S/PDIF Out header
2 x USB 3.0/2.0 headers
2 x USB 2.0/1.1 headers
1 x Trusted Platform Module (TPM) header
1 x Thunderbolt
™
add-in card connector
1 x serial port header
1 x Clear CMOS jumper
1 x audio gain control switch
Back Panel
Connectors
1 x PS/2 keyboard/mouse port
1 x D-Sub port
1 x DVI-D port
1 x HDMI port
1 x USB Type-C
™
port, with USB 3.1 support
1 x USB 3.1 Type-A port (red)
3 x USB 3.0/2.0 ports
2 x USB 2.0/1.1 ports
1xRJ-45port
1 x optical S/PDIF Out connector
5x audio jacks (Center/SubwooferSpeaker Out, Rear SpeakerOut, Line In,
Line Out, Mic In)
- 7 -
