Gigabyte GA-B85M-Gaming 3 (rev. 1.0) [4/36] Box contents
![Gigabyte GA-B85M-Gaming 3 (rev. 1.0) [4/36] Box contents](/views2/1669161/page4/bg4.png)
- 4 -
GA-B85M-Gaming 3 Motherboard Layout
The box contents above are for reference only and the actual items shall depend on the product package you obtain.
The box contents are subject to change without notice.
Box Contents
5 GA-B85M-Gaming 3 motherboard
5 Motherboard driver disk 5 Two SATA cables
5 User's Manual 5 I/O Shield
KB_MS
CPU_FAN
LGA1150
ATX
GA-B85M-Gaming 3
F_AUDIO
AUDIO
DDR3_1
BAT
F_PANEL
ATX_12V_2X4
Intel
®
B85
R_USB30
CODEC
M_BIOS
VGA
USB_LAN
PCIEX16
F_USB1
F_USB2
Intel
®
GbE LAN
iTE
®
Super I/O
DDR3_2
SATA3
3 2
1 0
PCIEX1_1
PCIEX1_2
F_USB30
SYS_FAN
SATA2
5 4
HDMI
