Gigabyte TRX40 DESIGNARE (rev. 1.0) [41/112] 3 favorites f11

BIOS Setup

- 41 -

2-3 Favorites (F11)

Set your frequently used options as your favorites and use the <F11> key to quickly switch to the page where

all of your favorite options are located. To add or remove a favorite option, go to its original page and press

<Insert> on the option. The option is marked with a star sign if set as a "favorite."
