![Gigabyte GA-78LMT-S2 R2 (rev. 1.0) [2/36] Copyright](/img/pdf.png)
Gigabyte GA-78LMT-S2 R2 (rev. 1.0) [2/36] Copyright
![Gigabyte GA-78LMT-S2 R2 (rev. 1.0) [2/36] Copyright](/views2/1669480/page2/bg2.png)
Motherboard
GA-78LMT-S2 R2
Sept. 20, 2017
Sept. 20, 2017
Motherboard
GA-78LMT-S2 R2
Copyright
© 2017 GIGA-BYTE TECHNOLOGY CO., LTD. All rights reserved.
The trademarks mentioned in this manual are legally registered to their respective owners.
Disclaimer
Information in this manual is protected by copyright laws and is the property of GIGABYTE.
Changes to the specications and features in this manual may be made by GIGABYTE without prior notice.
No part of this manual may be reproduced, copied, translated, transmitted, or published in any form or by
any means without GIGABYTE's prior written permission.
In order to assist in the use of this product, carefully read the User's Manual.
For product-related information, check on our website at: http://www.gigabyte.com
Identifying Your Motherboard Revision
The revision number on your motherboard looks like this: "REV: X.X." For example, "REV: 1.0" means the
revision of the motherboard is 1.0. Check your motherboard revision before updating motherboard BIOS,
drivers, or when looking for technical information.
Example:
