SPECIFICATION

MPS-45-3.3 MPS-45-5 MPS-45-7.5 MPS-45-12 MPS-45-13.5 MPS-45-15 MPS-45-24 MPS-45-27 MPS-45-48

MODEL

DCVOLTAGE

RATEDCURRENT

CURRENTRANGE

RATEDPOWER

OUTPUT

LINEREGULATION

LOADREGULATION

SETUP,RISETIME

HOLDUP TIME (Typ.)

VOLTAGERANGE

FREQUENCY RANGE

EFFICIENCY(Typ.)

INPUT

INRUSHCURRENT (Typ.)

LEAKAGECURRENT Note.7

WORKINGHUMIDITY

WORKINGTEMP.

STORAGETEMP.,HUMIDITY

TEMP.COEFFICIENT

VIBRATION

MTBF

DIMENSIONOTHERS

NOTE

PACKING

OVERLOAD

OVERVOLTAGE

ACCURRENT (Typ.)

3.3V 5V 7.5V 12V 13.5V 15V 24V 27V 48V

8A 8A 5.4A 3.7A 3.3A 3A 1.9A 1.7A 1A

0~10.7A 0~10.5A 0~7A 0~4.4A 0~3.9A 0~3.5A 0~2.2A 0~1.95A 0~1.1A

26.4W 40W 40.5W 44.4W 44.55W 45W 45.6W 45.9W 48W

52W(+3.3V:35W)with18CFMmin.Forcedairconvection

80mVp-p 100mVp-p 100mVp-p 100mVp-p 100mVp-p 100mVp-p 100mVp-p 100mVp-p 100mVp-p

3.0% 3.0% 3.0% 2.0%

2.0%

2.0% 2.0%

2.0%

1.0% 1.0% 1.0% 1.0% 1.0% 1.0% 1.0% 1.0% 1.0%

3.0% 3.0% 3.0% 2.0%

90~264VAC127~370VDC

47~440Hz

65% 72% 75% 76% 76% 77% 78% 78% 78%

1.2A/115VAC0.7A/230VAC

COLDSTART 17A/115VAC35A/230VAC

53~75W(3.3V:36~55W) ratedoutputpower

Protectiontype: Hiccupmode,recoversautomaticallyafterfaultconditionisremoved

-20~+85 ,10~95%RH

0.04%/ (0~50

10~500Hz,2G10min./1cycle,periodfor60min. eachalongX, Y,Zaxes

366.1Khrsmin.MIL-HDBK-217F(25 )

127*76*28mm(L*W*H)

0.18Kg;72pcs/15.1Kg/1.35CUFT

FileName:MPS-45-SPEC2012-05-22

800ms,30ms/230VAC1200ms,30ms/115VACatfullload

50ms/230VAC16ms/115VACatfullload

-10~+60 (Referto"DeratingCurve")

20~90%RHnon-condensing

SAFETY STANDARDS

ANSI/AAMIES60601-1, TUVEN60601-1,IEC60601-1approved

CompliancetoEN55011(CISPR11)ClassB, EN61000-3-2,-3

Complianceto EN61000-4-2,3,4,5,6,8,11,EN60601-1-2,medicallevel,criteria A

45WSingleOutputMedical Type

MPS-45 series

Universal AC input / Full range

Low leakage current <250 A

Protections: Short circuit / Overload / Over voltage

Cooling by free air convection

100% full load burn-in test

Fixed switching frequency at 45KHz

3 years warranty

Features :

1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25 of ambient temperature.

2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.

3. Tolerance : includes set up tolerance, line regulation and load regulation.

4. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets

EMC directives.

5. Mounting holes M1 and M2 should be grounded for EMI purposes.

6. Heat Sink HS1,HS2 can not be shorted.

7. .

For guidance on how to perform these EMC tests, please refer to EMI testing of component power supplies.

(as available on http://www.meanwell.com)

Touch current was measured from primary input to DC output

ENVIRONMENT

SAFETY &

EMC

(Note4)

PROTECTION

WITHSTANDVOLTAGE

ISOLATIONRESISTANCE

I/P-O/P:4KVACI/P-FG: O/P-FG:0.5KVAC2KVAC

I/P-O/P,I/P-FG:100MOhms/500VDC /25 /70%RH

RIPPLE&NOISE(max.) Note.2

VOLTAGETOLERANCE Note.3

OUTPUTPOWER(max.)

3.8~4.46V 5.75~6.75V 8.63~10.1V 13.8~16.2V 15.5~18.2V

17.25~20.25V

27.6~32.4V 31~36.45V

55.2~64.8V

VOLTAGE ADJ.RANGE

2.97~3.63V 4.5~5.5V 6.75~8.25V 10.8~13.2V 12.2~14.85V 13.5~16.5V 21.6~26.4V 24.3~29.7V 43.2~52.8V

EMCIMMUNITY

EMCEMISSION

Earthleakagecurrent<250 A/264VAC, Touchleakagecurrent<60 A/264VAC
