SPECIFICATION

PQ-100B PQ-100C

MODEL

DCVOLTAGE

RATEDCURRENT

CURRENTRANGE

RATEDPOWER

OUTPUT

VOLTAGE ADJ.RANGE

EFFICIENCY(Typ.)

INPUT

INRUSHCURRENT (Typ.)

LEAKAGECURRENT

WORKINGTEMP.

POWERGOOD

WORKINGHUMIDITY

STORAGETEMP.,HUMIDITY

TEMP.COEFFICIENT

VIBRATION

5V

CH1 CH1

-5V

CH3 CH3

12V

CH2 CH2

-12V

CH4 CH4

5V -5V15V -15V

10A 0.5A3.5A 0.5A 8A 0.5A3.5A 0.5A

2~10A 0~1A0.5~4.5A 0~1A 2~8A 0~1A0.5~4A 0~1A

100.5W 102.5W

80mVp-p 80mVp-p250mVp-p 120mVp-p 80mVp-p150mVp-p 150mVp-p80mVp-p

CH1:4.75~5.5V CH1:4.75~5.5V

5.0%

COLDSTART 50A

<1mA /240VAC

105%~135% ratedoutputpower

Protectiontype: Hiccupmode,recoversautomaticallyafterfaultconditionisremoved

Protectiontype: Hiccupmode,recoversautomaticallyafterfaultconditionisremoved

-10~+50 ,60

withcoolingfan(Referto"DeratingCurve")

1ms

20~90%RHnon-condensing

-20~+85 ,10~95%RH

CH1:5.75~6.75VDC

OVERVOLTAGE

SAFETY STANDARDS

UL60950-1, TUVEN60950-1approved

CompliancetoEN55022(CISPR22)ClassB, EN61000-3-2,-3

Complianceto lightindustrylevel,criteria AEN61000-4-2,3,4,5,6,11,

Features :

PQ-100 se ri es

ENVIRONMENT

SAFETY &

I/P-O/P:3KVACI/P-FG:1.5KVACO/P-FG:0.5KVAC

I/P-O/P,I/P-FG,O/P-FG:100MOhms/500VDC /25 /70%RH

RIPPLE&NOISE(max.) Note.2

VOLTAGETOLERANCE Note.3

1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25 of ambient temperature.

2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.

3. Tolerance : includes set up tolerance, line regulation and load regulation.

4. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets

EMC directives.

5. Heat Sink HS1,HS2 can not be shorted.

OUTPUTNUMBER

EMCIMMUNITY

EMCEMISSION
