120~160% ratedoutputpower
SPECIFICATION
CH1 CH2 CH3
MODEL
DCVOLTAGE
RATEDCURRENT
CURRENTRANGE
OUTPUT
LINEREGULATION
LOADREGULATION
SETUP,RISETIME
HOLDUP TIME (Typ.)
VOLTAGERANGE
FREQUENCY RANGE
EFFICIENCY (Typ.)
INPUT
INRUSHCURRENT (Typ.)
LEAKAGECURRENT
SAFETY STANDARDS
WORKINGTEMP.
WORKINGHUMIDITY
STORAGETEMP.,HUMIDITY
TEMP.COEFFICIENT
VIBRATION
MTBF
DIMENSIONOTHERS
NOTE
PACKING
OVERLOAD
OVERVOLTAGE
ACCURRENT (Typ.)
3.3V
6A
0~7A
50mVp-p
CH1:3~3.6V
+4,-2%
8.0%
8.0%
1.0%
3.0%
3.0%
1.0% 2.0%
3.0%
800ms,50msatfullload
60msatfullload
90~264VAC127~370VDC
47~63Hz
72%
1.8A/115VAC0.9A/230VAC
COLDSTART 20A/115V40A/230V
<1mA /240VAC
5.75~6.75Von+5V
Protectiontype: Hiccupmode,recoversautomaticallyafterfaultconditionisremoved
Protectiontype: Hiccupmode,recoversautomaticallyafterfaultconditionisremoved
UL60950-1, TUVEN60950-1approved
-10~+60
(Referto"DeratingCurve")
20~90%RHnon-condensing
-20~+85 ,10~95%RH
0.03%/ (0~50 )
10~500Hz,2G10min./1cycle,periodfor60min. eachalongX, Y,Zaxes
222Khrsmin.MIL-HDBK-217F(25 )
127*76*42mm(L*W*H)
0.28Kg;54pcs/16.2Kg/1.35CUFT
FileName:PT-6503-SPEC2011-08-18
6A 1A
0.2~10A 0~1.2A
50mVp-p 100mVp-p
5V 12V
CompliancetoEN55022(CISPR22)ClassB, EN61000-3-2,-3
CompliancetoEN61000-4-2,3,4,5,6,11,lightindustrylevel,criteria A
VOLTAGE ADJ.RANGE
65W TripleOutputwith3.3Voutput
PT-6503
Universal AC input / Full range
Protections: Short circuit / Overload / Over voltage
Cooling by free air convection
100% full load burn-in test
Fixed switching frequency at 65KHz
2 years warranty
Features :
WITHSTANDVOLTAGE
ISOLATIONRESISTANCE
I/P-O/P:3KVACI/P-FG:1.5KVACO/P-FG:0.5KVAC1min.
I/P-O/P,I/P-FG,O/P-FG:100MOhms/500VDC /25 /70%RH
RIPPLE&NOISE(max.) Note.2
VOLTAGETOLERANCE Note.3
ENVIRONMENT
SAFETY &
EMC
(Note4)
PROTECTION
1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25 of ambient temperature.
2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.
3. Tolerance : includes set up tolerance, line regulation and load regulation.
4. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets
EMC directives.
5. Mounting holes M1 and M2 should be grounded for EMI purposes.
6. Heat Sink HS1,HS2 can not be shorted.
For guidance on how to perform these EMC tests, please refer to EMI testing of component power supplies.
(as available on http://www.meanwell.com)
Totalpowermax.61.8W(CH1+CH2max.54W)RATEDPOWER
PT-6503
OUTPUTNUMBER
EMCIMMUNITY
EMCEMISSION
