Mechanical Specification
50.8
44.45
3.175
4- 3.3ψ
1
2
3
6
1
2
CN101
LED
SVR1
3.175
95.25
101.6
4
5
CN2
29
3 max.
1
2
3
FS1
CN1
T4A/250V
FS2
F4A/250V
FAN
10CFM
direction
Air flow
5cm
※Note
RPS-200 series
Top View
Side View
200W Reliable Green Medical Power Supply
RPS-200 (PCB Type)
File Name:RPS-200-SPEC 2019-08-01
