Cable Installation

Before the installation and use, please read carefully the relevant content in “Warning and

Safety instructions”.

NOTE:

• When you plug or unplug the TV, computer or other equipments, you must make sure

that the AC power has been already shut down;

• When unplugging the power cable or signal cable, please hold the plug (the insulated

part), do not draw the body of the cable.

2. The RF output terminal can be connected with the RF input port of the TV.

3. The output AV terminal of DVD can be connected with the AV input port of the TV

through AV cable.

NOTE:

4. The output COMPONENT(YPbPr) terminal of DVD can be connected with the

COMPONENT(YPbPr) input port of the TV through AV cable.

5. Connect one end of the VGA cable with the VGA port on computer, connect the other

end of the VGA cable with the VGA port on the TV, and tighten the bolts clockwise on

the each end of VGA cable.

NOTE:

• While connecting the 15-pin VGA, please do not insert the plug overexertedly, for fear

the pin might be broken.

6. Connect one end of the HDMI cable with HDMI output port, connect the other end of

the HDMI cable with the HDMI port on the TV.

NOTE:

• While connecting the HDMI, please aim at carefully, do not insert overexertedly, for fear

the pin might be broken.

7. The AV output of the TV can be connected with the input port of other AV equipment

through AV cable.

NOTE:

8. Check and make sure that all AV cables are connected with the corresponding ports

correctly.

NOTE：

power input port with the AC power out of the above range.

• Please hold the insulated part of the plug when you are unplugging the power cable, do

not touch directly the metallic part of the cable.

• Component and AV1 can not be used at same time for they share of one audio channel.

1. Take out the TV from the wrapping package and put it in a drafty and flat place.

• AV OUT can output TV/AV channels' audio&video signal.

• The range of power input for the TV is /50Hz, 60Hz, do not connect the TV

9. Connect the AC power cable with AC power supply.

100-240V

LED 3245 DWHDR (Smart)

TELEVISION LIBERTON
