SPECIFICATION
MODEL
DC VOLTAGE
RATED CURRENT (20.5CFM)
RATED POWER (convection) Note.7
CURRENT RANGE (20.5CFM)
OUTPUT
VOLTAGE ADJ. RANGE
LINE REGULATION
LOAD REGULATION
SETUP, RISE TIME
HOLD UP TIME (Typ.)
VOLTAGE RANGE Note.6
FREQUENCY RANGE
POWER FACTOR (Typ.)
EFFICIENCY (Typ.)
INPUT
INRUSH CURRENT (Typ.)
LEAKAGE CURRENT Note.9
SAFETY STANDARDS
WORKING TEMP.
WORKING HUMIDITY
STORAGE TEMP., HUMIDITY
TEMP. COEFFICIENT
VIBRATION
OVERLOAD
OVER VOLTAGE
OVER TEMPERATURE
AC CURRENT (Typ.)
1800ms, 30ms/230VAC 3500ms, 30ms/115VAC at full load
90 ~ 264VAC 127 ~ 370VDC
16ms/230VAC/115VAC at full load
47 ~ 63Hz
PF>0.93/230VAC PF>0.98/115VAC at full load
1.8A/115VAC 0.9A/230VAC
COLD START 35A/115VAC 70A/230VAC
105 ~ 135% rated output power
105℃(TSW1)detect on heatsink of power transistor
90℃(TSW2 )detect on heatsink of power transistor
Protection type : Hiccup mode, recovers automatically after fault condition is removed
Protection type : Shut down o/p voltage, re-power on to recover
CH1: 5.75 ~ 6.75V
Protection type : (TSW2)Shut down o/p voltage, re-power on to recover
Protection type : (TSW1)Shut down o/p voltage, recovers automatically after temperature goes down
ANSI/AAMI ES60601-1, TUV EN60601-1 approved
-20 ~ +70℃ (Refer to "Derating Curve")
20 ~ 90% RH non-condensing
-40 ~ +85℃, 10 ~ 95% RH
±0.03%/℃ (0 ~ 50℃)
10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes
160W Triple Output Medical Type
RPT-160 series
‧
‧
‧
‧
‧
‧
‧
‧
‧
‧
‧
■
WITHSTAND VOLTAGE
ISOLATION RESISTANCE
I/P-O/P:4KVAC I/P-FG:2KVAC O/P-FG:1.5KVAC
I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25℃/ 70% RH
SAFETY &
EMC
(Note 4)
PROTECTION
ENVIRONMENT
CURRENT RANGE (convection)
RIPPLE & NOISE (max.) Note.2
RATED POWER (20.5CFM) Note.8
VOLTAGE TOLERANCE Note.3
POWER GOOD / POWER FAIL
Power on: PS-ON = "Hi" or " > 2 ~ 5V" ; Power off: PS-ON = "Low" or " < 0 ~ 0.5V"
500ms>PG>10ms PF>1ms
FUNCTION
Compliance to EN55011 (CISPR11), EN55022 (CISPR22) Class B, EN61000-3-2,-3
MTBF
DIMENSIONOTHERS
Compliance to EN61000-4-2,3,4,5,6,8,11, EN55024, EN60601-1-2, EN61204-3, medical level, criteria A
191.4K hrs min. MIL-HDBK-217F (25℃)
127*76.2*34.6mm (L*W*H)
PACKING
0.33Kg; 36pcs/12.9Kg/0.79CUFT
NOTE
 









 
84%
CH1 CH1 CH1 CH1OUTPUT NUMBER
RPT□-160A
5V
14A
0.6 ~ 9A
0.6 ~ 14A
14A
0.6 ~ 9A
0.6 ~ 14A
98.6W
145W
100mVp-p
CH1:5 ~ 5.5V
±2.0%
±0.5%
±1.5%
RPT□-160B RPT□-160C RPT□-160D
12V
CH2 CH2 CH2 CH2
-5V
CH3 CH3 CH3 CH3
12V -12V 15V 12V-15V 24V5V 5V 5V
5.5A
0.2 ~ 3.8A
0.2 ~ 5.5A
5A
0.2 ~ 3.4A
0.2 ~ 5A
1A
0.1 ~ 0.6A
0.1 ~ 1A
1A
0.1 ~ 0.8A
0.1 ~ 1A
3.6A 5A
0.1 ~ 2.6A 0.2 ~ 2.6A
0.1 ~ 3.6A 0.2 ~ 5A
1A 1.2A
0.1 ~ 0.8A
0.15 ~ 1A
0.1 ~ 1A
0.15 ~ 1.2A
14A 11A
0.6 ~ 9A 0.3 ~ 8A
0.6 ~ 14A 0.3 ~ 11A
98.4W
146W
99W 98.2W
143W 147.8W
120mVp-p 120mVp-p 100mVp-p 120mVp-p 120mVp-p 150mVp-p 120mVp-p
150mVp-p
200mVp-p
100mVp-p
100mVp-p
±5.0% -5,+7% ±5.0% -4,+5% ±4.0% ±5.0%±8.0% +7,-5%
±1.0% ±1.0% ±1.0% ±1.0% ±1.0% ±1.0%±1.0% ±1.0%
±3.0% -5,+6% ±3.0% -4,+5% ±3.0% ±3.0%±8.0% -3,+4%
±2.0% ±2.0% ±2.0%
±0.5%
±1.5%
±0.5% ±0.5%
±2.0% ±1.5%
84% 83% 83%
5V STANDBY (G model)
5VSB : 5V@0.6A without fan, 0.8A with fan 20.5CFM ; tolerance ± 2%, ripple : 50mVp-p(max.)
RPT 160A
G
consumption < 0.75 W
G: With 5Vsb & no load power
Blank: Basic function (without 5Vsb)
PS-ON INPUT SIGNAL (G model)
EMC IMMUNITY
EMC EMISSION
Earth leakage current < 200 A/264VAC , Touch current < 100 A/264VAC
μ
μ
ISOLATION LEVEL
Primary-Secondary: 2xMOPP, Primary-Earth:1xMOPP, Secondary-Earth:1xMOPP
File Name :RPT-160-SPEC 2014-12-17
