MEAN WELL RPT-65F-C [2/3] Series

MEAN WELL RPT-65F-C [2/3] Series
Case No. 946A Unit:mm
DC Output Connector (CN2 ) : Molex 5273-06 or equivalen t
Pin No.
1,2
3,4
5
6
Assignment
V1
GND
V2
V3
Mating Housing
Molex 519 5
or equivalent
Terminal
Molex 5194
or equivalent
AC Input Connector (CN1) : Molex 5273-03 or eq uivalent
Pin No.
1
2
3
Assignment Mating Housing
Mo lex 5195
Molex 5194
or equivalent
or equivalent
Terminal
Mechanical Specification
1
3
CN1
3
1
2
CN2
5
4
6
SVR1
2
5.6115.8
127
FS1
18CFM min.
FAM
(60W convection, 77W wit h FAN)
Optional cover:
No. 946A-T
Optional L- Bracket:
No. 946A-D
Block Diagram
fosc : 65KHz
O.V.P.
CONTROL
+V1
COM
RECTIFIERS
&
FILTER
SWITCHING
POWER
FILTER
&
RECTIFIERS
O.L.P.
DETECTION
CIRCUIT
PWM
FILTER
FILTER
&
&
RECTIFIERS
RECTIFIERS
+V2
V3
FG
I/P
FILTE R
EMI
65W Triple Output Switching Power Supply
RP T-6 5
se rie s
AC/L
No Pin
AC/N
File Na me:RP T-65-SPEC 201 3-05-27
