D -808 C – 08/01 A – EN Pag. 56/72
Electrical resistances power supply
Each compressor comes with an electrical resistance located in the compressor’s lower area. Its purpose is to warm the
lubricating oil and thus avoid the mixing of refrigerant fluid within.
It is therefore necessary to ensure that the resistances are powered at least 24 hours before the planned start-up time.
To ensure that they are activated, it is sufficient to keep the machine on by closing the general disconnecting switch Q10.
The microprocessor, however, has a series of sensors that prevent the compressor from being started up when the oil
temperature is not at least 5°C above the saturation temperature corresponding to the current pressure.
Keep the Q0, Q1, Q2 and Q12 switches in the Off (or 0) position until the machine is to be started up.
Emergency Stop
The machine has an emergency stop system which cuts off power to the compressors, allowing the machine to stop
safely in case of danger. The emergency stop is triggered off by pressing the red mushroom button on the door of the
machine’s electrical panel.
After the machine has stopped, an alarm signal is generated in the unit control card, which reports the triggering of the
emergency stop and prevents the re-starting of the compressors. To restart the compressors:
− Reset the emergency button
− Cancel the alarm in the control card.
CAUTION
The emergency button cuts off electrical power to the compressors, but not to the machine electrical panel. Take all
necessary precautions therefore, if action must be taken on the machine subsequent to an emergency stop.
