D -808 C – 08/01 A – EN Pag. 4/72
General information
IMPORTANT
The units described in the present manual represent a valuable investment. Maximum care should be taken to
ensure correct installation and appropriate working conditions of the units.
A maintenance contract with a authorized service centre is highly recommended.
CAUTION
This manual provides information about the features and procedures for the complete series.
All units are delivered from factory as complete sets which include wiring diagrams and dimensional drawings with
size, weight and features of each model.
WIRING
DIAGRAMS AND DIMENSIONAL DRAWINGS MUST BE CONSIDERED ESSENTIAL DOCUMENTS OF
THIS MANUAL
In case of any discrepancy between this manual and the two aforesaid documents, please refer to the wiring diagram
and dimensional drawings.
Safe use and maintenance of the unit, as explained in this Maintenance and Use Manual, is fundamental to prevent any
accidents occurring to operators during both operation and maintenance as well as during repair work.
Therefore, it is highly recommended that this document be read carefully, complied with and stored safely.
Warnings for the operator
• READ THIS MAINTENANCE AND USE MANUAL BEFORE USING THE UNIT
• THE OPERATOR MUST BE TRAINED AND INSTRUCTED ON HOW TO USE THE UNIT
• THE OPERATOR MUST STRICTLY FOLLOW ALL INSTRUCTIONS, SAFETY REGULATIONS AND
LIMITATIONS REGARDING THE USE OF THE UNIT.
Assistance
Should additional maintenance be required, it is advisable to consult authorised staff before carrying out any repair work.
Spare parts
Spare parts to be used for maintenance of the unit must be original. Therefore, always consult the manufacturer.
Receiving the machine
The machine must be inspected for any possible damage immediately upon reaching its final place of installation. All
components described in the delivery note must be carefully inspected and checked; any damage must be reported to
the carrier. Before connecting the machine to earth, check that the model and power supply voltage shown on the
nameplate are correct. Responsibility for any damage after acceptance of the machine cannot be attributed to the
manufacturer.
Checks
To prevent the possibility of incomplete delivery (missing parts) or transportation damage, please perform the following
checks upon receipt of the machine:
a) Before accepting the machine, please verify every singlecomponent in the consignment. Check for any damage.
b) In the event that the machine has been damaged, do not remove the damaged material. A set of photographs
are helpful in ascertaining responsibility.
c) Immediately report the extent of the damage to the transportation company and request that they inspect the
machine.
d) Immediately report the extent of the damage to the manufacturer representative, so that arrangements can be
made for the required repairs. In no case must the damage be repaired before the machine has been inspected
by the representative of the transportation company.
