06
EWWQ-AJYnn(A)
sPecIFIcatIoNs
SPECIfICATIonS
Nominal capacity cooling kW
Capacity steps %
Nominal input cooling kW
Eer
Eseer
Casing colour / material
Dimensions (HxWxD) mm
Weight machine weight / operational weight kg
Water heat exchanger
evaporator
type
water volume l
water ow rate nominal l/sec
nominal water pressure drop cooling kPa
Water heat exchanger
condenser
type
water volume l
water ow rate nominal l/sec
nominal water pressure drop cooling kPa
model quantity
Compressor
type
model quantity
Sound level
sound Power / sound Pressure
cooling dBA
Refrigerant circuit
refrigerant type
refrigerant charge kg
no of circuits / refrigerant control
Piping connections evaporator water inlet/outlet / condensor water inlet/outlet
Power supply
Nominal capacity cooling kW
Capacity steps %
Nominal input cooling kW
Eer
Eseer
Casing colour / material
Dimensions (HxWxD) mm
Weight machine weight / operational weight kg
Water heat exchanger
evaporator
type
water volume l
water ow rate nominal l/sec
nominal water pressure drop cooling heat exchanger kPa
Water heat exchanger
condenser
type
water volume l
water ow rate nominal l/sec
nominal water pressure drop cooling kPa
model quantity
Compressor
type
model quantity
Sound level
sound Power / sound Pressure
cooling dBA
Refrigerant circuit
refrigerant type
refrigerant charge kg
no of circuits / refrigerant control
Piping connections evaporator water inlet/outlet / condensor water inlet/outlet
Power supply
Nominal capacity cooling kW
Capacity steps %
Nominal input cooling kW
Eer
Eseer
Casing colour / material
Dimensions (HxWxD) mm
Weight machine weight / operational weight kg
Water heat exchanger
evaporator
type
water volume l
water ow rate nominal l/sec
nominal water pressure drop cooling heat exchanger kPa
Water heat exchanger
condenser
type
water volume l
water ow rate nominal l/sec
nominal water pressure drop cooling kPa
model quantity
Compressor
type
model quantity
Sound level
sound Power / sound Pressure
cooling dBA
Refrigerant circuit
refrigerant type
refrigerant charge kg
no of circuits / refrigerant control
Piping connections evaporator water inlet/outlet / condensor water inlet/outlet
Power supply
Nominal cooling capacity and power input are based on 12/7 °C entering/leaving water temperature and 35 °C ambient temperature. Power input is for the whole unit.
EWWQ400AJYNN EWWQ480AJYNN EWWQ600AJYNN EWWQ650AJYNN EWWQ750AJYNN EWWQ800AJYNN
387.96 474.13 574.36 651.45 742.14 812.53
25-100 (stepless) 12.5-100 (stepless)
87.37 106.27 130.44 147.86 169.73 175.22
4.44 4.46 4.40 4.41 4.37 4.64
4.95 4.98 4.97 4.97 4.72 5.37
RAL7032 / Galvanized and painted steel sheet
1,846x 1,065 x 3,431 2,000x 1,226x 3,440 1,846x 1,266x 3,561 2,170x 1,350x 4,902
1,933 / 2,135 1,967 / 2,169 2,283 / 2,543 2,332 / 2,628 2,407 / 2,777 3,921 / 4,422
Shell and tube
124 118 176 170 274 344
18.53 22.65 27.44 31.12 35.41 38.81
49.43 64.65 45.04 47.92 54.74 53.80
Shell and tube
79 92 84 126 97 79 + 79
22.87 27.92 33.91 38.46 43.87 47.52
60.15 64.35 67.91 66.02 16.46 64.44
1 2
Semi-hermetic single screw compressor
1 2
100.2 / 82.2 101.2 / 83.0 102.3 / 83.9 102.3 / 83.9 101.5 / 83.2 104.7 / 84.0
R-410A
80 90 100 85
1 / EEV 2 / EEV
168.30 / 5’’ 168.30 / 5’’ 219.10 / 5’’ 219.10 / 6” 219.10 / 5’’
400V/50Hz/3~
EWWQC14AJYNN EWWQC15AJYNN EWWQC16AJYNN EWWQC17AJYNN EWWQC18AJYNN EWWQC19AJYNN
1,281.09 1,352.09 1,488.14 1,620.34 1,783.43 1,928.13
12.5-100 (stepless)
279.05 296.39 339.95 375.37 408.72 441.58
4.59 4.56 4.38 4.32 4.36 4.37
5.35 5.29 4.93 4.82 4.89
RAL7032 / Galvanized and painted steel sheet
2,455 x 1,350 x 4,835 2,547 x 1,350 x 4,844 2,547 x 1,350 x 4,844 2,547 x 1,350 x 4,809
4,536 / 5,200 4,607 / 5,280 4,988 / 5,602 4,999 / 5,615 5,053 / 5,670 5,204 / 5,881
Shell and tube
538 505 495 539
61.19 64.59 71.00 77.28 85.09 91.99
50.28 55.40 59.86 69.74 89.42 98.78
Shell and tube
60 + 68 68 + 68 54 + 54 54 + 57 61 + 61 61 + 77
75.07 79.32 87.96 96.01 105.48 114.02
73.40 69.77 16.52 19.31 16.93 17.08
2
Semi-hermetic single screw compressor
2
106.5 / 86.9 105.8 / 86.2 106.2 / 86.6 106.6 / 87 107.1 / 87.5
R-410A
100 / 100 130 / 130
2 / EEV
273.00 / 5” 273.00 / 6”
400V/50Hz/3~
EWWQ950AJYNN/A EWWQC10AJYNN/A EWWQC11AJYNN/A EWWQC12AJYNN/A EWWQC13AJYNN/A EWWQC14AJYNN/A
993 1,059 1,139 1,182 1,297 1,397
25-100 (stepless) 12.5-100 (stepless) 25-100 (stepless) 12.5-100 (stepless)
196.57 209.49 232.06 233.11 257.5 274.8
5.05 5.06 4.91 5.07 5.04 5.08
5.39 5.89 5.28 5.87 5.88 5.98
RAL7032 / Galvanized and painted steel sheet
2,001x 1,448x 3,891 2,453x 1,350x 4,985 2,001x 1,448x 3,891 2,453x 1,350x 4,985
2,427 / 3,056 4,4775 / 5,431 2,457 / 3,086 4,831 / 5,479 4,873 / 5,512 4,919 / 5,546
Shell and tube
538 587 538 575 563 551
46.00 49.07 52.74 54.77 60.10 64.71
53.85 53.69 68.89 64.23 55.13 67.85
Shell and tube
91 69 + 70 91 73 + 76 76 + 76 75 + 86
55.84 59.56 64.35 66.44 73.00 78.48
64.73 40.10 83.56 47.93 48.17 49.20
1 2 1 2
Semi-hermetic single screw compressor
1 2 1 2
102.9 / 84.0 105.2 / 85.6 103.8 / 84.9 105.6 / 86.0 106.1 / 86.5 106.5 / 86.9
R-410A
130 120 / 120 130 120 / 120
1 / EEV 2 / EEV 1 / EEV 2 / EEV
219.10 / 5’’ 273.00 / 5’’
400V/50Hz/3~
