D – KIMWC00412-09EN -8/88
NOMENCLATURE
EWW D 360 EJ YN N /A
Machine type
ERA: Air-cooled condensing unit
EWW: Water cooled packaged water chiller
EWL: Remote condenser water chiller
EWA: Air-cooled chiller, cooling only
EWY: Air-cooled chiller, heat pump
EWC: Air-cooled chiller, cooling only with centrifugal fan
EWT: Air-cooled chiller, cooling only with heat recovery
Refrigerant
D: R-134a
P: R-407C
Q: R-410A
Capacity class in kW (cooling)
Always 3-digit code
Cap < 50 kW: not rounded: example: 37 kW => 037
50 < Cap < 999 kW: rounded 0/5: 536 kW => 535
Cap > 999 kW use C-symbol (C=100): example: 2578 kW => C26
Model series
first character : letter A, B,…: major modification
second character : letter A,B,... : minor modification DENV
letter J-W… : minor modification New Series
Voltage
V1: ~ / 220 - 240 V / 50 Hz
V3: 1~ / 230 V / 50 Hz
T1: 3~ / 230 V / 50 Hz
W1: 3N~ / 400 V / 50 Hz
Y1: 3~ / 380-415 V / 50 Hz
YN: 3~ / 400 V / 50 Hz
Hydraulic module/Heat recovery version/Pump &
electrical options (Consult Selection software)
N: No Hydraulic components
M: Modular
A-V: Combination of specific options
Option regarding efficiency version, sound version
/H: High ambient version
/A: High efficiency version
/Q: Extra low noise version
/Z: High efficiency and Extra low noise version
