MEAN WELL HDP-190 Data Sheet онлайн

Universal AC input / Full range

Built-in active PFC function

High efficiency up to 86%

Protections: Short circuit / Overload / Over voltage / Over temperature

Cooling by free air convection

1U low profile 36mm

Conformal coated

ZVS technology to reduce power dissipation

LED indicator for power on

 years warranty3

SPECIFICATION

HDP-190

MODEL

OUTPUT

VOLTAGE RANGE

Note.5

FREQUENCY RANGE

POWER FACTOR (Typ.)

EFFICIENCY (Typ.)

INPUT

ENVIRONMENT

INRUSH CURRENT (Typ.)

LEAKAGE CURRENT

OVER TEMPERATURE

SAFETY STANDARDS

SAFETY &

EMC

(Note 4)

WITHSTAND VOLTAGE

ISOLATION RESISTANCE

WORKING TEMP.

WORKING HUMIDITY

STORAGE TEMP., HUMIDITY

TEMP. COEFFICIENT

VIBRATION

MTBF

DIMENSIONOTHERS

NOTE

PACKING

OVERLOAD

OVER VOLTAGE

PROTECTION

AC CURRENT (Typ.)

+3.8V +2.8V

33A 20A

0 ~ 40A 0 ~ 22A

181.4W (typ.) 192W (max.)

100mVp-p 100mVp-p

3.6 ~ 4V 2.5 ~ 3V

±2.0% ±2.0%

±0.5% ±0.5%

±2.0% ±2.0%

1000ms, 50ms/230VAC 2500ms, 50ms/115VAC at full load

16ms/230VAC 16ms/115VAC at full load

90 ~ 264VAC 127 ~ 370VDC

47 ~ 63Hz

PF 0.94/230VAC PF 0.98/115VAC at full load

≧≧

2.7A/115VAC 1.1A/230VAC

30A/115VAC 45A/230VAC

<0.7mA / 240VAC

V1: 4.37 ~ 5.13V

Protection type : Shut down o/p voltage, re-power on to recover

Shut down o/p voltage, re-power on to recovery

Compliance to EN61000-4-2,3,4,5,6,8,11, EN55024, EN61000-6-2, heavy industry level, criteria A

I/P-O/P:3KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC

I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25 / 70% RH℃

-30 ~ +70 (Refer to "Derating Curve")℃

20 ~ 90% RH non-condensing

-40 ~ +85 , 10 ~ 95% RH℃

±℃ ℃0.03%/ (0 ~ 50 )

10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes

111.3K hrs min. MIL-HDBK-217F (25 )℃

215*115*36mm (L*W*H)

■ Features :

1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25 of ambient temperature.℃

2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.

3. Tolerance : includes set up tolerance, line regulation and load regulation.

4. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets

EMC directives.

5. Derating may be needed under low input voltages. Please check the derating curve for more details.

6. Output voltage between V1 and V2 should be higher than 1.0V(V1-V2 1.0V).≧

HDP-190

190W Dual Output with PFC Function

0.95Kg; 15pcs/15.3Kg/0.7CUFT

86%

File Name:HDP-190-SPEC 2015-02-28

V1 V2

OUTPUT NUMBER

DC VOLTAGE

RATED CURRENT

CURRENT RANGE (max.)

RATED POWER

VOLTAGE ADJ. RANGE

Note.6

LINE REGULATION

LOAD REGULATION

SETUP, RISE TIME

HOLD UP TIME (Typ.)

RIPPLE & NOISE (max.) Note.2

VOLTAGE TOLERANCE Note.3

EMC IMMUNITY

EMC EMISSION

192W continue. V1 total power output shall not exceed 160W (max. 40A) ; V2 total power output shall not exceed 66W (max. 22A)

(The V1 & V2 combine total power output shall not exceed 192W)

OUTPUT POWER (max.)

V2: 3.22 ~ 3.78V

V1+V2: 105 ~ 150% max. output power ; or V2: 125 ~ 170% rated current

Protection type: Hiccup mode, recovers automatically after fault condition is removed

UL60950-1, TUV EN60950-1, CCC GB4943.1 approved

Compliance to EN55022 (CISPR22), GB9254, class B, EN61000-3-2,-3, GB17625.1
