Installation Manual
Please refer to : http://www.meanwell.com/webnet/search/InstallationSearch.html
Mechanical Specification
Case No.994D Unit:mm
※ IP65 rated. Output voltage and constant current level can be adjusted through internal potentiometer.
(Can access by removing the rubber stopper on the case.)
A Type: HEP-150-_A(standard model)
※IP68 rated. Cable for I/O connection.
Blank: HEP-150(optional model)
150W Single Output Switching Power Supply
HEP-150 series
File Name:HEP-150-SPEC 2015-05-28
300 20±
FG (Green/Yellow)
SJTW 14AWG 2C×
SJTW 18AWG 3C×
228
204
AC/L(Brown)
AC/N(Blue)
12
9.6
9.49.4 34.2
68
ψ4.2 4PL×
300 20±
+V(Red)
-V(Black)
38.8
102
Tcase
34
※ T case: Max. Case Temperature.
Vo
ADJ.
Io
ADJ.
300 20±
FG (Green/Yellow)
SJTW 14AWG 2C×
38.8
SJTW 18AWG 3C×
228
204
AC/L(Brown)
AC/N(Blue)
12
9.6
9.49.4 34.2
68
ψ×4.2 4PL
300 20±
+V(Red)
-V(Black)
102
Tcase
34
※ T case: Max. Case Temperature.
