D-EOMHP00706-14EN - 35/78
with Glycol
ON
x
Ice with Glycol
Network
x
x
Cool
Cool with Glycol
Ice
Ice with Glycol
Ice with
Glycol
x
x
x
x
Ice with Glycol
x
Test
x
x
x
x
Test
Note: “x” indicates those settings can be ignored.
5.3 Unit Status
The displayed unit status should be determined by the conditions in the following table.
Enum
Unit status
Conditions
0
AUTO
Unit in normal operation
1
AUTO Wait For Load
Unit state = Auto, with no circuits running and LWT error is less than startup delta T.
2
AUTO Evap Recirc
Unit state = Auto, Evaporator pump started
3
AUTO Wait For Flow
Unit state = Auto, waiting for evaporator flow switch to close
4
AUTO Pumpdown
All running circuits in Pumpdown state
5
AUTO Max Pulldown
Unit State = Auto, pulldown rate has met or exceeded the limit
6
AUTO Unit Cap Limit
Unit State = Auto, unit capacity has met or exceeded the limit
7
AUTO Current Limit
Unit State = Auto, unit current has met or exceeded the limit
8
AUTO Noise Reduction
Noise reduction is active
9
OFF Unit Alarm
Unit Alarm is active
10
OFF Ice mode timer
In Ice mode, and ice cycle timer is active
11
OFF All Cir Disable
All circuits are unavailable
12
OFF Keypad Disable
Unit Enable set point = Disable
13
OFF BAS Disable
Control Source = Network, and BAS Enable = false
14
OFF Remote Switch
Remote switch is open
15
OFF Unit Switch
Unit switch is disable
16
OFF Cfg Chg, Need Rst
Configuration has been changed and controller needs to be reset
17
OFF Test Mode
In Test mode
